Adjustable Rear Leg Solar Mount for Roof

Xiamen Honor Energy's Adjustable Rear Leg Solar Mount for Roof For Wholesale Procurement. Featuring a universal and standardized design, this mount is highly versatile for various color steel tile rooftop solar projects. Its unified structure enables large-scale bulk stocking, effectively reducing inventory pressure and shortening delivery cycles for mass orders.

Made of high-strength anodized aluminum alloy, the mount delivers reliable structural stability, excellent corrosion resistance and long outdoor service life. The simple assembly structure requires no special tools, enabling fast, convenient and labor-saving installation. It is an ideal solar racking solution for residential, commercial and industrial rooftop PV projects.

Product Specifications

Application Environment

This adjustable tilt solar mounting bracket is designed for color steel tile rooftop PV projects. It supports multiple tilt angle ranges to match different site latitude and power generation requirements:

1. 10–15° tilt range: Suitable for regions with low latitude and abundant sunlight. It reduces wind load on the roof, fits low-pitch color steel roofs well, and is widely used for commercial rooftop solar systems.

2. 15–30° tilt range: This range is widely applied in many temperate and subtropical rooftop PV projects. Balances power output and wind resistance, applicable for most temperate and subtropical zones. This range delivers optimal annual power generation performance for general rooftop projects.

3. 30–60° tilt range: For high-latitude areas or locations with weak solar irradiance. Larger tilt helps snow sliding and improves sunlight capture in winter. Note: higher angles bring greater wind load, and roof structural verification is required before installation.

The whole bracket adopts anodized aluminum material, good corrosion resistance, suitable for outdoor environments including coastal, dusty and high-temperature regions. Not recommended for heavy chemical corrosion environments without extra protective treatment.

Installation Instruction

1. Positioning: Mark mounting points for bracket bases on color steel tile roof. Ensure points are on the load-bearing ridge of metal tiles.

2. Fix Base: Fasten bracket bases onto color steel tiles with matched clamps. Make sure bases fit tightly against roof surface without warping.

3. Assemble Adjustable Rear Leg: Hinge rear support leg with front base. Align holes on rear leg according to required tilt angle (10–15° /15–30° /30–60°), insert bolts and pre-tighten.

4. Final Tightening: Double-check tilt angle, torque all bolts to specification. Inspect all connections, installation completed.

The certification

The product is manufactured under an ISO 9001 quality management system.

FAQ

Q：What tilt angles can this mount support?

A：Adjustable Rear Leg Solar Mount for Roof supports adjustable angles of 10–15°,15–30°,30–60°, you can select the angle according to local latitude and power generation requirements.

Q：What roof types is this bracket suitable for?

A：Designed for color steel tile metal rooftops. The base must be installed on the load-bearing corrugation of the tile.

Q：What material is the solar mount made of?

 A：High-strength aluminum alloy with anodized treatment, excellent corrosion resistance for outdoor use.

Q：Do I need special tools for installation?

 A：No special tools required. Only common wrenches are needed for assembly and bolt tightening.

Q：What environment is this bracket applicable to?

A：Suitable for high-temperature, dusty and coastal salt-spray areas. Extra protection is needed for heavy chemical corrosion sites.

Q：Can it withstand strong wind or hurricane load?

A：The structure is calculated for wind load. Roof structure inspection is required before installation, especially for large tilt angles (30–60°).

Q：What is your warranty period?

 A：We provide 10-year product warranty for the aluminum mounting structure.

Q：Is bulk stock available for wholesale orders?

A：Yes. Standardized design enables mass stocking and fast delivery for large orders.
